The L-VCP06D-W is a 4-inch recessed ceiling speaker designed for PA and Voice Alarm systems.
It complies with AS ISO 7240.24 Type A and is suitable for flush or surface mounting.
This white ceiling speaker delivers clear and intelligible audio and meets the 100dB SPL requirement for emergency warning applications.
| Models | SMX+650-1L-PS5, SMX+900-1L-PS5, SMX+900-1L-PS11, SMX+650-1L-PS11GL, SMX+12U1LPS11, SMX+28U1LPS11, SMX+40U1LPS11, SMX+40U1LPS11, LCM-320, LEM-320 |
|---|
| Part Number | L-VCP06D-W |
|---|---|
| Speaker Type | 4″ Recessed Ceiling Loudspeaker |
| Compliance | AS ISO 7240.24 Type A |
| Mounting | Flush mount or surface mount (with optional box) |
| Rated Power | 6W (9W maximum) |
| Power Taps | 0.375W, 0.75W (default), 1.5W, 3W, 6W |
| Line Voltage | 100V |
| Sound Pressure Level | 91dB @ 1W, 1m / Max 100.5dB @ 6W, 1m |
| Frequency Response | 200Hz – 15kHz |
| Ceiling Cut-out | 140mm Ø |
| Dimensions (Recessed) | 160mm Ø × 75mm (70mm recess) |
| Weight | 0.66 kg |
| Colour | White (RAL9003) |
| IP Rating | IP21 |
| Line Monitoring | Capacitor fitted |
