The L-VCP06D-BK is a compact 4-inch ceiling speaker designed for PA and emergency warning systems.
Certified to AS ISO 7240.24 Type A, it supports flush and surface mounting and provides high-intelligibility audio.
The black finish suits modern commercial and architectural interiors.
| Models | SMX+650-1L-PS5, SMX+900-1L-PS5, SMX+900-1L-PS11, SMX+650-1L-PS11GL, SMX+12U1LPS11, SMX+28U1LPS11, SMX+40U1LPS11, SMX+40U1LPS11, LCM-320, LEM-320 |
|---|
| Part Number | L-VCP06D-BK |
|---|---|
| Speaker Type | 4″ Recessed Ceiling Loudspeaker |
| Compliance | AS ISO 7240.24 Type A |
| Mounting | Flush mount or surface mount (with optional box) |
| Rated Power | 6W (9W maximum) |
| Power Taps | 0.375W, 0.75W (default), 1.5W, 3W, 6W |
| Line Voltage | 100V |
| Sound Pressure Level | 91dB @ 1W, 1m / Max 100.5dB @ 6W, 1m |
| Frequency Response | 200Hz – 15kHz |
| Ceiling Cut-out | 140mm Ø |
| Dimensions (Recessed) | 160mm Ø × 75mm (70mm recess) |
| Weight | 0.66 kg |
| Colour | Black (RAL9004) |
| IP Rating | IP21 |
| Line Monitoring | Capacitor fitted |
