D4A (Medium Velocity Nozzles) Protectospray Directional Spray Nozzle, Open

D4A (Medium Velocity Nozzles) Protectospray Directional Spray Nozzle, Open

Description

All TYCO Nozzles PDF

Like other Protectospray nozzles, the D4A is open, non-automatic, and releases a cone of medium-velocity water droplets. But unlike other Protectospray nozzles, the D4A features a four-arm body design that helps protect the unit from mechanical or physical damage. This unit releases a cooling spray to prevent excessive heat absorption, possible structural damage, or the spread of fire to protected equipment. In some applications, the D4A nozzles may also be used for fire control or extinguishment.

Technical Specification



Property Specification
Brand Tyco
Model Series Tyco D4A Nozzles
Thread size 1/2″
K-Factor Up to 7.2
Orientation Directional
Maximum Working Pressure 175 psi (12 bar)
Finish Options NFB, TCB
Compliance UL and C-UL Listed
Reference Datasheet TFP806

Product specifications, approvals, and availability are subject to change without notice.
Always refer
to the latest Tyco Fire Protection Products datasheets for complete and current information.
