The CZ-6 Six Zone Interface Module is an intelligent addressable interface device designed to integrate up to six conventional initiating device circuits (IDCs) into compatible intelligent fire alarm systems. Manufactured by System Sensor (Honeywell), the CZ-6 provides a reliable solution for expanding addressable systems while allowing existing or dedicated conventional detection zones to be monitored through an intelligent signalling line circuit (SLC).

The CZ-6 supports six supervised conventional input circuits, providing continuous monitoring of connected field wiring and initiating devices. Each input zone can be connected to approved conventional detectors and initiating devices, allowing the fire alarm control panel to receive accurate alarm and fault information through the addressable network.

The module communicates through the intelligent SLC and uses six consecutive addresses. A single rotary address setting assigns the base address, with additional addresses automatically assigned for the remaining input zones. Unused zones can be disabled to simplify system programming and commissioning.

Designed for large-scale commercial and industrial applications, the CZ-6 provides a modular installation solution using the CH-6 chassis with compatible BB-6 or BB-2 cabinets. Individual bi-colour LED indicators provide clear status indication for each monitored input, supporting efficient testing, maintenance, and fault identification.

Key Features

• Six-channel intelligent addressable zone interface module
• Integrates conventional initiating device circuits into intelligent systems
• Six supervised conventional input zones
• Intelligent SLC communication
• Uses one base address plus five automatically assigned addresses
• Up to two unused zones can be disabled
• Panel-controlled bi-colour LED status indicators
• Operating voltage: 15–32 VDC
• Low standby current design
• Compatible with CH-6 chassis and BB-series cabinets
• UL Listed for approved fire alarm applications

The System Sensor CZ-6 Six Zone Interface Module provides a flexible and dependable method of connecting conventional detection devices to addressable fire alarm systems, delivering enhanced monitoring capability, simplified system expansion, and reliable fault reporting.
