ENscape sounder are a high quality device designed to alert building occupants in the event of an emergency. The product features a new folded horn design which provides outstanding sound output at low current draw.
With its modern design, global tone set and extensive installer friendly features, the ENscape
sounder is the logical choice for specifiers, installers and distributors.
| Models | SMX+650-1L-PS5, SMX+900-1L-PS5, SMX+900-1L-PS11, SMX+650-1L-PS11GL, SMX+12U1LPS11, SMX+28U1LPS11, SMX+40U1LPS11, SMX+40U1LPS11, LCM-320, LEM-320 |
|---|
| Product Code | CWSO-RR-S1 |
|---|---|
| Type | Non-Addressable Audible Sounder |
| Application | Indoor |
| Standards | EN54-3 |
| Body Colour | Red |
| Mounting | Wall or ceiling |
| Base Type | Low-Profile Base (Included) |
| Ingress Protection | IP21C |
| Operating Voltage | 9–29 VDC |
| Max Sound Output | Up to 107 dB(A) @ 1 m |
| Tones | 32 Selectable (Including Bell Tone) |
| Volume Settings | Two Levels (High / Medium) |
| Operating Temperature | -25°C to +70°C |
