| Property | Specification |
|---|---|
| Brand | Tyco |
| Model Series | Tyco TY-B Sprinklers |
| Operating element | 5 mm Bulb |
| Response | Standard Response, Standard Coverage |
| Thread size | 1/2″, 3/4″ |
| K-Factor | 5.6, 8.0 |
| Orientation | Pendent , Upright, Horizontal, Recessed, Conventional, Vertical Sidewall |
| Temperature Ratings °F | 135, 155, 175, 200, 286, 360 |
| Maximum Working Pressure | 175 psi (12 bar) |
| Finish Options | SS, SMO, Titanium |
| Compliance | LPCB, Lloyds |
| Reference Datasheet | TFP680 |
Product specifications, approvals, and availability are subject to change without notice.
Always refer to the latest Tyco Fire Protection Products datasheets for complete and current information.
