| Property | Specification |
|---|---|
| Brand | Tyco |
| Model Series | Tyco WS Sprinklers |
| Operating element | 3 mm Bulb |
| Response | Fast Response |
| Thread size | 1/2″ |
| K-Factor | 5.6 |
| Orientation | Horizontal and Pendent Vertical Sidewall |
| Temperature Ratings °F | 155, 200 |
| Maximum Working Pressure | 175 psi (12 bar) |
| Finish Options | B, C, SW, JB |
| Compliance | UL, C-UL, NYC, ICC |
| Reference Datasheet | TFP620 |
Product specifications, approvals, and availability are subject to change without notice.
Always refer to the latest Tyco Fire Protection Products datasheets for complete and current information.
