The L-VJP15A/EN-W is a 15W unidirectional projection speaker designed for PA-VA and evacuation systems.
Certified to AS ISO 7240.24 Type B, it delivers clear and intelligible speech with reliable performance in indoor and outdoor environments.
The white, low-profile ABS housing and adjustable U-bracket allow easy installation and precise sound direction.
| Models | SMX+650-1L-PS5, SMX+900-1L-PS5, SMX+900-1L-PS11, SMX+650-1L-PS11GL, SMX+12U1LPS11, SMX+28U1LPS11, SMX+40U1LPS11, SMX+40U1LPS11, LCM-320, LEM-320 |
|---|
| Part Number | L-VJP15A/EN-W |
|---|---|
| Speaker Type | Unidirectional Projection Speaker |
| Compliance | AS ISO 7240.24:2015 Type B |
| Rated Power | 15W |
| Maximum Power | 25W |
| Power Tappings | 0.95W / 1.9W / 3.75W / 7.5W / 15W |
| Input Voltage | 100V Line |
| Maximum SPL | 101 dB @ 15W, 1m |
| Frequency Response | 160Hz – 15kHz |
| Speaker Driver | 127mm (5″) |
| Dispersion Angle | 150° Horizontal / 210° Vertical @ 1kHz |
| Dimensions | 137mm Ø × 218mm |
| Surface Mount Dimensions | 258mm (L) × 218mm (D) × 140mm (W) |
| Weight | 1.6kg |
| Colour | White (RAL9003) |
| Material | ABS Housing, Stainless Steel Bracket |
| IP Rating | Type B (AS7240.24), IP33 Certified, IP65 Rated |
| Operating Temperature | -25°C to +55°C |
| Line Monitoring | Capacitor fitted |
