| Property | Specification |
|---|---|
| Brand | Tyco |
| Model Series | Tyco SD Sprinklers |
| Operating element | Solder |
| Response | Fast Response |
| Thread size | 1/2″ |
| K-Factor | 5.6 |
| Orientation | Attic Single Directional |
| Temperature Ratings °F | 212 |
| Maximum Working Pressure | 175 psi (12 bar) |
| Compliance | UL, C-UL |
| Reference Datasheet | TFP610 |
Product specifications, approvals, and availability are subject to change without notice.
Always refer to the latest Tyco Fire Protection Products datasheets for complete and current information.
