| Property | Specification |
|---|---|
| Brand | Tyco |
| Model Series | Tyco TY-B (Old Style) Sprinklers |
| Operating element | 5 mm Bulb |
| Response | Standard Response, Standard Coverage |
| Thread size | 1/2″, 3/4″ |
| K-Factor | 5.6, 8 |
| Orientation | Conventional (Old Style) |
| Temperature Ratings °F | 135, 155, 175, 200, 286, 360 |
| Maximum Working Pressure | 175 psi (12 bar) |
| Finish Options | B, Wh, L, WOL, C, W |
| Compliance | UL, C-UL, VdS, LPCB-(TY3650 Only) |
| Reference Datasheet | TFP661, TFP662, TFP663, |
Product specifications, approvals, and availability are subject to change without notice.
Always refer to the latest Tyco Fire Protection Products datasheets for complete and current information.
