HT-C807 – LED Twin Spots Emergency Light

HT-C807 – LED Twin Spots Emergency Light

Description

The HT-C807 – LED Twin Spot Emergency Light is a reliable emergency lighting solution designed to provide strong illumination during power outages. Featuring two adjustable LED spotlight heads, it delivers wide-area lighting to help clearly illuminate exit paths and critical areas. Built with durable construction and designed for surface wall or ceiling mounting, this unit is ideal for commercial buildings, corridors, stairwells, plant rooms, and utility spaces. Powered by a LiFePO4 battery, it offers more than 3 hours of emergency operation and complies with AS/NZS 2293 emergency lighting standards.

Key Features

  • Twin adjustable LED spotlights for wide emergency lighting coverage
  • High brightness output – 400 lumens
  • Surface-mounted design for wall or ceiling installation
  • LiFePO4 3.2V 3000mAh battery for reliable backup power
  • Emergency duration: over 3 hours
  • Recharge time: 24 hours
  • Durable and compact housing for commercial environments
  • Energy-efficient LED technology with long lifespan
  • Suitable for corridors, stairways, plant rooms, warehouses, and utility areas
  • Compliant with AS/NZS 2293 emergency lighting requirements

Specifications

Specification Details
Product Name LED Twin Spot Emergency Light
Model No. HT-C807
Brand FFA
Unit Of Measure each
Mounting Type Surface Mounted
Input Voltage AC 220–240V
Frequency 50/60Hz
Power 2.5W
Luminous Flux 400 lm
Power Factor 0.2
Supply Current 40 mA
LED Configuration 2 × LED Heads (40 + 40 LEDs)
Battery LiFePO4 3.2V 3000mAh
Emergency Duration > 3 hours
Recharge Time 24 hours
Operating Temperature 0–40°C
Fuse 1A 250V / 3.15A 250V
Cable 1.5 m Cable Plug
Standard Compliance AS/NZS 2293
Warranty 3 Years (Battery excluded)

Technical Documents

Download Product Guide

Download IES File
