| Property | Specification |
|---|---|
| Brand | Tyco |
| Model Series | Tyco ESFR Series Sprinklers |
| Operating element | Solder and Bulb |
| Response | Early Suppression, Fast Response |
| Thread size | 3/4″, 1″, 1-1/4″ |
| K-Factor | 14.0, 16.8, 22.4, 25.2, 33.6 |
| Orientation | Pendent, Upright, Pendent |
| Temperature Ratings °F | 165, 212 |
| Maximum Working Pressure | 175 psi (12 bar) |
| Compliance | UL, C-UL, FM, NYC, LPCB, VdS |
| Reference Datasheet | TFP338, TFP312, TFP321, TFP32116, TFP317, TFP320, TFP319, |
Product specifications, approvals, and availability are subject to change without notice.
Always refer to the latest Tyco Fire Protection Products datasheets for complete and current information.
