FFA-BLADE100 –Recessed Universal Blade Exit Light

FFA-BLADE100 –Recessed Universal Blade Exit Light

Product Description

The FFA-BLADE100 – Recessed Universal Blade Exit Light offers a modern, low-profile design for emergency exit signage with a clean recessed mount. Featuring an energy-efficient edge-lit LED blade, this exit light provides clear and bright illumination, ensuring safe and easy evacuation routes in commercial, retail, and public buildings.

Designed for flexibility, the FFA-BLADE100 supports multiple directional legend inserts (left, right, and straight) and complies fully with AS/NZS 2293 emergency lighting standards. Its recessed installation delivers a flush finish, ideal for contemporary interiors where aesthetics and functionality are equally important.

Key Features:

  • Edge-lit LED blade for clear, stylish illumination
  • Recessed mounting for a sleek, flush finish
  • Compatible with interchangeable exit legends (left, right, straight)
  • Energy-efficient LED technology with long operational life
  • Compliant with AS/NZS 2293 emergency lighting standards
  • Suitable for offices, hotels, retail stores, and public spaces

Specifications

Product Name FFA-BLADE100 –Recessed Universal Blade Exit Light
Model No FFA-BLADE100
Brand FFA
Type Recessed Universal Blade Exit Light
Installation Type Recessed
Viewing Distance 24 m
Dimensions 364mm x 100.5mm x 228.6mm
Colour Temperature (CCT) 5000K
Colour Rendering Index (CRI / Ra) 80
Wattage 2W
Input Voltage 220-240V
Input Current 40mA
LED Model SMD 2835
LED Quantity 18 PCS
Luminous Flux 25.83 lm
Emergency Power 2W
Emergency Duration ≥3 hours
Emergency Output Voltage 3.8V
Emergency Output Current 600mA
Battery Type LiFePO4
Battery Capacity 3.2V 1300mAh
Charging Voltage 3.8V
Charging Current 120mA
Charger Power 4W
Charging Time 16 hours
Max Ambient Temp 0°C-40°C
LED Lifetime 50,000 hours
Standard AS 2293.3
Warranty 3 Years (Excluding Battery)
