Fire Sprinkler System Logbook (DRY-PIPE / PRE-ACTION / DELUGE & WATER SPRAY)

Fire Sprinkler System Logbook (DRY-PIPE / PRE-ACTION / DELUGE & WATER SPRAY)

Description

BDP-PR-DWS – Fire Sprinkler System Logbook DRY-PIPE / PRE-ACTION / DELUGE & WATER SPRAY

A practical two-year logbook designed for recording routine service activities for Dry-Pipe, Pre-Action, Deluge and Water Spray sprinkler systems in accordance with AS 1851—2012 (Incorporating Amendment 1). It provides dedicated fields for pressure readings, air compressor tests, alarm operation times, nitrogen pressure, valves, foam testing, defects and corrective actions, helping technicians maintain clear and consistent service records. Where applicable, relevant Wet Pipe Sprinkler service activities are recorded separately in the associated logbook.

Specifications

Specification Details
Product Name Dry-Pipe / Pre-Action / Deluge & Water Spray Systems Logbook
Product Code BDP-PR-DWS
Size 295 × 210 mm
Copy Type 3-Part Carbonless
Copies White – Owner / Occupier / Agent · Yellow – Service Provider · Red – Book Copy
Record Period 2 Years
Standard AS 1851—2012 – Routine Service of Fire Protection Systems & Equipment (Incorporating Amendment 1)
Service Intervals Monthly · Six-Monthly · Yearly · Five-Yearly
Applicable Systems Dry-Pipe Sprinkler Systems · Pre-Action Sprinkler Systems · Deluge Systems · Water Spray Systems
Relevant Standard Section AS 1851—2012, Section 2 – Automatic Fire Sprinkler Systems
Relevant Service Schedules Tables 2.4.3.1, 2.4.3.2, 2.4.3.3, 2.4.3.4 · 2.4.4.1, 2.4.4.2, 2.4.4.3, 2.4.4.4 · 2.4.5.1, 2.4.5.2, 2.4.5.3, 2.4.5.4
Additional Records System Air Pressure · Pressure Gauge Readings · Air Compressor Cut-In / Cut-Out · Low Air Pressure Alarms · Nitrogen Cylinder Pressure · Alarm Operation Times · Foam Quality · Defects / Corrective Actions · Notes
Associated Service Records Applicable Wet Pipe Sprinkler service activities under Tables 2.4.2.1–2.4.2.4 are to be completed and recorded in the relevant logbook.
Writing Shield Included to help prevent transfer onto following carbonless pages
